Technical principle of Chinese patent medicine powder moisture analyzer
Moisture is essential for the medicinal material. Keeping the proper moisture of the medicinal material first can maintain the efficacy of the Chinese medicinal material, and the second is beneficial for storage. Moisture is of great significance to ensure the quality of traditional Chinese medicine decoction pieces. It is especially important to control the moisture content of the purchased Chinese medicine decoction pieces. The reasonable moisture can prevent insects and mildew during storage and storage, avoid decomposition of active ingredients, enzymatic hydrolysis and so on. . Guanya CS series Chinese patent medicine powder moisture analyzer application range: Chinese herbal medicine, Chinese herbal medicine, decoction pieces, extracts, proprietary Chinese medicines, semi-finished products, plants, animals, minerals, capsules and other pharmaceutical processes in the detection and control of moisture.
Chinese patent medicine powder moisture analyzer technical specifications:
1, weighing range: 0-120g
2. Moisture measurement range: 0.01%-100%
Dry weight measurement range: 100%-0.01%
3, test mode: LCD touch fast
4. Imported monomer weighing system
5, sample quality: 120g
6, heating temperature range: 22.1-205.9 ° C
Temperature error: ±0.5 °C
Temperature resolution: 0.1 ° C
Heating source: special annular heating source
★ A new moisture meter heating treatment system equipment
★ A moisture detecting device for agricultural and forestry products
8, water content readability: 0.01%.
9, display: color 7 inch touch screen
10, ★ display: IPS 7 color LCD touch screen
Ambient temperature display error: ±0.5 °C
11, 8 parameters:
★Moisture value (%), dry weight (%), current temperature (°C), set temperature (°C),
Current weight (g), initial weight (g), test time (S), discrimination time (S)
12, operation mode: screen touch
13. Dimensions: 380×205×325 (mm)
14, power: 220V / frequency: 50Hz ± 1Hz
15, net weight: 4.5Kg
Traditional Chinese medicine village has many varieties and complex attributes. The main sources are plants, animals and minerals. Among them, there are many kinds of plant medicinal materials. Because of the influence of natural conditions and their own nature, they all contain certain water, and the water content is It varies depending on its composition and internal structure. The amount of water content of Chinese medicinal materials is an important indicator for ensuring quality during storage, and is also the main factor affecting the quality of medicinal materials in the treasury, and plays a leading role in quality changes. Therefore, we must pay attention to the research and management of water. The 2010 edition of the Chinese Pharmacopoeia has limited the water content of more than 30 kinds of medicinal materials such as clove, asparagus and bezoar. This article talks about the relationship between water and medicinal materials from the aspects of insect pests, mildew, taste, discoloration, deliquescence, weathering, etc., in order to cause the attention of the production, management and use of Chinese herbal medicines.
Chinese patent medicine powder moisture analyzer technical principle:
The CS series Chinese patent medicine powder moisture analyzer produced by Shenzhen Guanya Technology Co., Ltd. can quickly measure the moisture content and solid content of various samples such as slurry, powder, paste, fiber, sheet, etc. In the field of solid content detection, not only a moisture proposal for a quick drying structure is provided, but also a new equipment certificate for the moisture treatment system of the moisture meter is obtained. The display part of Guanya brand moisture meter adopts high-resolution 7-inch LCD large screen, which can directly test parameters and condition settings on the LCD screen directly through the full-screen touch mode, which realizes no personnel training and personnel care. , maintenance of the experimental process, high-tech automatic mode; see the manual or product operation process can be fully grasped and operated, and at the same time according to the instructions on the manual, you can easily deal with various phenomena appearing in the work of the equipment. The crown-halogen moisture analyzer can be used to measure the moisture content of any substance. The instrument starts according to the principle of pyrolysis weight, the moisture meter determines the sample weight, and then the sample is rapidly heated by the built-in halogen drying device and moisture evaporator. During the process, the instrument continuously measures the weight of the sample and displays the lost moisture. At the end of the drying, the moisture content or the dry matter content is shown as the end result. In practical applications, the speed of the heating, therefore, is comparable to conventional infrared heating or ovens, such as halogen drying devices, which require less time to reach large heating powers, while the instrument can also use high temperatures. It is another factor that reduces drying time. Uniform heating of the sample material ensures good drying results allow a small amount of sample to be used.
